Dayliff DSD 5

The Dayliff DSD 5 range consists of high-performance, multistage centrifugal pumps engineered specifically for drawing water from underground sources like wells and boreholes. Built with durability in mind, these pumps are designed to withstand harsh conditions while delivering a steady water supply.

These pumps stand out due to their robust construction and ability to handle sand content better than standard models.

Features of Dayliff DSD5

• Sand-Resistant Design: By using high-quality polycarbonate for the impellers and diffusers, these pumps offer superior resistance to sand wear, ensuring a significantly longer lifespan.
• Durable Materials: The housing, shaft, and couplings are made from AISI 304 stainless steel, while the suction and delivery chambers are crafted from heavy-duty cast iron.
• Ready-to-Install Kits: The popular DSD 5/10 and DSD 5/18 models come as complete packages, including a 30-meter cable and a dedicated control box for immediate setup.

Motor

Every Dayliff DSD 5 pump is powered by a stainless steel, liquid-cooled motor designed for continuous underwater operation. To keep your pump running safely, it is essential to use the correct control system:

•  Enclosure Class: IP68
• Insulation Class: B
• Speed: 2850 rpm

Operating Conditions

• Pumped liquid: Thin, clean, chemically non-aggressive liquids with a max. sand content of 0.25%
• Max. Water temperature: +35°C
• Max. immersion depth: 150m
• Min. borehole diameter: 110m
