DAVIS
DAVIS – 4” Submersible Pumps with Peripheral Impeller
- DAVIS 0.75Kw 75m, 3m3/h
Features
- Motor and Pump Casing: AISI304 S/S
- Impeller: Brass-Radial Peripheral Vane
- Motor: Continuous Duty (Dry, Rewindable Stator) Diameter, 101mm.
- Installation: Vertical / Horizontal
- Maximum Immersion Depth: 40m
- Liquid Temperature: 40oC
- Application: Domestic Wells, Tank, Irrigation (Using Pressure Tanks)
- Integrated Capacitor & Thermal Overload Protector
- 20m & 40m Cable
Inquire about this product
Description
Pedrollo DAVIS pumps are 4” submersible pumps with close-coupled peripheral impellers. It features an integrated capacitor and thermal overload protector, designed for the transfer of clean water with no abrasive particles. Compact and cost-effective. It works effectively with small pressure tanks; thus, it is ideal for all irrigation needs.
Pump Construction
- Delivery Port: Cast Iron
- Pump Sleeve: Stainless steel AISI 304
- Impeller: Brass
- Pump Cover: Cast Iron
- Shaft: Stainless steel AISI 431
Davis Specifications
- Flow rate: 3.0 m³/h
- Max Head: 75m
- Liquid Temperature: up to +40 °C
- Maximum operating depth below water level: 40 m.
Conditions for Use
- Liquid temperature up to +40 °C
- Depth of use up to 40 m below water level (with an appropriately sized power cable)
- Vertical and horizontal operation
